APC BX1600MI Back UPS 1600VA - Inverter with AVR, Battery Backup & Surge Protection, Data Protection

Main Specifications

• Run Time for Load: 900 W
• Min-Max Power: 90-900 W
• Max Capacity Used: 100%
• Main Input Voltage: 230 V
• Rated Power: 900 W
• Rated Power in VA: 1600 VA
• Product Type: Uninterruptible Power Supply (UPS)
• Output Connection Type: 4 Universal
• Cable Length: 1.2 m
• Number of Cables: 1
• Battery Type: Lead-Acid Battery

Battery & Runtime

• Runtime: [View Runtime Graph]
• Efficiency: [View Efficiency Graph]
• Number of Battery-Filled Slots: 0
• Number of Battery-Free Slots: 0
• Battery Recharge Time: 8 hours
• Battery Voltage: 24 V
• Battery Life: 3 to 5 years
• Replacement Battery: APCRBC176
• Battery Graph Comments: Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0).
• Extended Runtime: 0

General Information

• Provided Equipment: User Manual
• Number of Power Module-Filled Slots: 0
• Number of Power Module-Free Slots: 0
• Redundant: No

Physical Specifications

• Color: Black
• Height: 19 cm
• Width: 14 cm
• Depth: 39 cm
• Weight: 10.3 kg
• Mounting Preference: No Preference
• Mounting Mode: Not Rack-Mountable
• Two Post Mountable: 0
• USB Compatible: No

Input Specifications

• Network Frequency: 50/60 Hz +/- 5 Hz Auto-Sensing
• Input Voltage Limits: 140-300 V
• Input Power Factor at Full Load: 0.56

Output Specifications

• Maximum Configurable Power (W): 900 W
• Output Frequency: 50/60 Hz +/- 1 Hz (Synchronized to Mains)
• UPS Type: Line Interactive
• Wave Type: Stepped Approximation to a Sinewave
• Full Load Runtime: 00:01:00 at 900 W
• Half Load Runtime: 00:06:30 at 450 W
• Maximum Configurable Power (VA): 1600 VA
• Transfer Time: 6 ms typical, 10 ms maximum

Conformance & Certifications

• Product Certifications: CE
• Standards:
  • EN/IEC 62040-1:2019/A11:2021
  • EN/IEC 62040-2:2006/AC:2006
  • EN/IEC 62040-2:2018
• Equipment Protection Policy: Lifetime coverage up to €50,000

Environmental Conditions

• Ambient Air Temperature for Operation: 0…40 °C
• Relative Humidity: 0…95% Non-Condensing
• Operating Altitude: 0…3000 m
• Ambient Air Temperature for Storage: -15…40 °C
• Storage Relative Humidity: 0…95% Non-Condensing
• Storage Altitude: 0…3000 m
• Acoustic Level: 40 dBA
• IP Degree of Protection: IP20

Communications & Management

• Control Panel: LED Status Display (Online & On Battery)

Surge Protection & Filtering

• Surge Energy Rating: 273 J

Packing Units

• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package 1 Dimensions (H x W x L): 29.7 cm x 49.5 cm x 23.5 cm
• Package 1 Weight: 11.3 kg
• SCC14: 10731304410727
