Canon imageFORMULA DR-C240 Document Scanner

The Canon imageFORMULA DR-C240 is a high-performance, compact desktop scanner designed to meet the demanding needs of businesses and busy work environments. It delivers fast, reliable scanning for a wide range of document types, including IDs, passports, long documents, and thick media — all while maintaining superior image quality and efficiency.

Key Features:

• Type: Desktop sheet-fed scanner

• Sensor: CMOS CIS 1 Line Sensor

• Optical Resolution: Up to 600 dpi

• Light Source: RGB LED

• Scanning Modes: Simplex / Duplex

• Interface: High-Speed USB 2.0

Performance:

• Black & White Scanning Speed: Up to 45 ppm / 90 ipm

• Colour Scanning Speed: Up to 30 ppm / 60 ipm

• Output Resolution Options: 150 to 600 dpi

• Daily Duty Cycle: 3,500 – 6,000 scans/day

Media Handling:

• Document Size:

  • Width: 50.8 – 216 mm

  • Length: 54 – 356 mm (up to 3000 mm in long document mode)

• Paper Weight: 27 – 209 g/m² (0.06 – 0.25 mm)

• Business Cards, Plastic Cards, and Passports Supported

• Feeder Capacity: Up to 60 sheets (80 g/m²)

• Separation Method: Retard Roller

Advanced Features:

• Auto Page Size Detection & Deskew

• 3D Colour Correction

• Colour Dropout & Enhancement (RGB)

• Auto Colour Detection

• Shadow Cropping & Background Smoothing

• MultiStream Output

• Blank Page Skip & Folio Mode

• Double Feed Detection (Ultrasonic Sensor)

• Barcode & 2D Code Recognition

Power & Environmental:

• Power Supply: AC 100–240V (50/60Hz)

• Power Consumption:

  • Scanning: ≤ 19W

  • Sleep Mode: ≤ 1.4W

  • Power Off: ≤ 0.1W

• Operating Temperature: 10 – 32.5°C

• Humidity Range: 20 – 80% RH

• Compliance: RoHS

Dimensions & Weight:

• Trays Closed: 291 x 253 x 231 mm

• Trays Opened: 291 x 603 x 363 mm

• Weight: Approx. 2.8 kg

Bundled Software:

• Windows: ISIS/TWAIN Drivers, CaptureOnTouch Pro, Kofax VRS, DR Management Tool

• Mac: TWAIN Driver, CaptureOnTouch, Kofax VRS

Optional Accessories:

• A4 Flatbed Scanner Unit 102

• A3 Flatbed Scanner Unit 202

• NA10/WA10 Network Adapters

• Carrying Case

This scanner is ideal for government offices, healthcare, legal, education, and any business requiring fast, high-volume document capture with precision and flexibility.
