EZVIZ H1C 1080p WiFi Security Camera, Mini Baby Monitor Camera with Night Vision for Home

Specifications

Model: CS-H1C

Camera

• Image Sensor: 1/3" Progressive Scan CMOS
• Shutter Speed: Self-adaptive shutter
• Lens: 2.8mm, View Angle: 108° (Diagonal), 91° (Horizontal), 50° (Vertical)
• Minimum Illumination: 0.5 Lux @(F2.2, AGC ON), 0.1 Lux with IR
• Lens Mount: M12
• Day & Night: IR-cut filter with auto-switching
• DNR: 3D DNR
• IR Night Vision Distance: Up to 32 ft / 10 m

Video & Audio

• Max. Resolution: 1920 × 1080
• Frame Rate: Max: 25 fps; Self-Adaptive during network transmission
• Video Compression: H.264
• H.264 Type: Main Profile
• Video Bit Rate: HD; Standard, Adaptive bit rate
• Audio Bit Rate: Self-Adaptive
• Max. Bitrate: 1 Mbps

Functionality

• Smart Alert: Motion detection
• Two-way Talk: Supports
• General Features: Anti-Flicker, Dual-Stream, Heartbeat, Mirror Image, Password Protection, Watermark

Network

• Standard: IEEE802.11b, 802.11g, 802.11n
• Frequency Range: 2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth: Supports 20 MHz
• Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
• Transmission Rate:
  • 11b: 11 Mbps
  • 11g: 54 Mbps
  • 11n: 72 Mbps
• Wi-Fi Pairing: AP pairing
• Protocol: EZVIZ Cloud Proprietary Protocol
• Interface Protocol: EZVIZ Cloud Proprietary Protocol

Storage

• Local Storage: Supports microSD card (up to 512 GB)
• Cloud Storage: Supports EZVIZ CloudPlay storage (subscription required)

General

• Operating Conditions: -10 ºC ~ 45 ºC (14 °F ~ 113 °F), Humidity 95% or less (non-condensing)
• Power Supply: DC 5V / 1A
• Power Consumption: Max. 3.0 W
• Dimensions: 53.89 × 53.89 × 90.3 mm (2.12 × 2.12 × 3.56 inches)
• Packaging Dimensions: 91.5 × 87.5 × 149 mm (3.60 × 3.44 × 5.87 inches)
• Net Weight: 87 g (3.07 oz)
• Weight (With Package): 305 g (10.76 oz)

In the Box

• H1C Camera ×1
• Power Adapter ×1
• 2-Meter Power Cable ×1
• Foam Sticker ×2
• Metal Plate ×1
• Regulatory Information ×2
• Quick Start Guide ×1

Certifications

• CE / RoHS / WEEE / REACH
