EZVIZ 4-Piece Security Sensor Kit with Wi-Fi, PIR Human Motion Detector, Open/Close Door/Window Sensor CS-B1-A0-A34

Home Gateway (Model: CS-A3-A0-W)

General

• Operation Conditions:
  • Temperature: -10°C to 55°C (14°F to 131°F)
  • Humidity: 95% or less (non-condensing)
• Dimensions: Φ 70.0 × 25.4 mm (Φ 2.75 × 1.00 inch)
• Net Weight: 71 g (2.5 oz)
• Package Size: 95.5 × 80.5 × 98.5 mm (3.8 × 3.2 × 3.9 inch)
• Power Supply: Micro USB, DC 5V / 1A
• Power Consumption: Max. 3W

Network

• Communication Methods:
  • RJ45 interface network cable
  • Wi-Fi 2.4 GHz
  • ZigBee 3.0
• Communication Distance:
  • Wi-Fi (2.4 GHz):
  • ZigBee 3.0:
• Antenna: Built-in

PIR Sensor (Model: CS-T1C-A0-BG)

General

• Operation Conditions:
  • Temperature: -10°C to 55°C (14°F to 131°F)
  • Humidity: 95% or less (non-condensing)
• Dimensions:
  • Main Body: Φ 43.5 × 32.0 mm (1.7 × 1.3 inch)
  • Base: Φ 29.0 × 9.5 mm (1.1 × 0.4 inch)
• Package Size: 92 × 52 × 93 mm (3.6 × 2.0 × 3.7 inch)
• Weight: 92 g (3.2 oz) with package

Detection

• Type: Passive infrared (PIR)
• Detection Distance: Up to 7 m (23 ft)
• Detection Angle: 90° horizontal, 90° vertical
• Recommended Installation Height: 1.8 to 2.5 m for wall-mounted installation
• Pet-Proof Detection: Requires pet shield and installation height of ≥ 50 cm above pet

Function

• Low Battery Reminder: Supports
• Anti-Tamper Alarm: Supports
• Installation Methods: Adhesive back with magnetic parts, supports wall and ceiling flip-over installation

Battery

• Type: CR2450
• Life:
  • High-performance mode: Up to 1 year
  • Energy-saving mode: Up to 2 years

Network

• Protocol: ZigBee 3.0
• Communication Distance:

Open/Close Sensor (Model: CS-T2C-A0-BG)

General

• Operation Conditions:
  • Temperature: -10°C to 55°C (14°F to 131°F)
  • Humidity: 95% or less (non-condensing)
• Dimensions:
  • Main Body: 53.5 × 22.5 × 13.5 mm (2.1 × 0.9 × 0.5 inch)
  • Magnet: 32.0 × 10.5 × 13.5 mm (1.2 × 0.4 × 0.5 inch)
• Package Size: 92 × 52 × 93 mm (3.6 × 2.0 × 3.7 inch)
• Weight: 80 g (2.8 oz) with package

Detection

• Recommended Trigger Distance:
  • Wooden Door: > 25 mm
  • Iron Door: > 15 mm

Function

• Low Battery Reminder: Supports
• Anti-Tamper Alarm: Supports
• Installation Method: Adhesive back for peel-and-stick installation

Battery

• Type: CR1632 × 2
• Life: Up to 2 years (Based on 30 detections per day)

Network

• Protocol: ZigBee 3.0
• Communication Distance:

Smart Button (Model: CS-T3C-A0-BG)

General

• Operation Conditions:
  • Temperature: -10°C to 55°C (14°F to 131°F)
  • Humidity: 95% or less (non-condensing)
• Dimensions: Φ 40.6 × 12.3 mm (Φ 1.6 × 0.5 inch)
• Package Size: 92 × 52 × 93 mm (3.6 × 2.0 × 3.7 inch)
• Weight: 68 g (2.4 oz) with package

Control Methods

• Single Click:
• Double Click: Interval time
• Long Press: ≥ 2 s

Modes

• Arm / Disarm Mode
• Emergency Button Mode

Function

• Low Battery Reminder: Supports
• Anti-Tamper Alarm: Supports
• Installation Method: Place anywhere; adhesive back for peel-and-stick installation

Battery

• Type: CR2032
• Life: Up to 2 years (Based on 15 clicks per day)

Network

• Protocol: ZigBee 3.0
• Communication Distance:

In the Box

• A3 Home Gateway
• Power Adapter for A3
• USB Cable for A3
• T1C PIR Sensor
• Pet Shield for T1C
• T2C Open/Close Sensor
• T3C Smart Button
• Doubled-sided Tape Strips (3)
• Regulatory Information
• Quick Start Guide
