EZVIZ DL50FVS Smart Lock, 8-in-1 Keyless Entry, 3D Face Recognition, 8GB Built-in Storage

Model: CS-DL50FVS

Material & Dimensions

• Panel Material: Aluminum alloy
• Panel Size:
  • Front panel: 400 × 72 × 22.5 mm
  • Rear panel: 400 × 72 × 30.5 mm
• Color: Metallic grey
• Lock Body Type: Automatic Mechanical Detection lock body
• Lock Cylinder: C-level cylinder
• Emergency Charging: Type-C
• Working Power: 5000mAh rechargeable Lithium batteries

Technical Specifications

• Unlocking Methods:
  • Face ID
  • Fingerprint
  • Passcode
  • Mechanical key
  • Bluetooth Key via EZVIZ App
  • Temporary codes
  • Remote unlock
• User Capacity: 50 users
• Fingerprint Capacity: 50 fingerprints
• Passcode Capacity: 50 codes
• Face ID Capacity: 50 IDs
• Communication Methods: 2.4GHz Wi-Fi, Bluetooth
• Screen (Non-touchable): IPS, 4 inches
• IP Grade: IP54
• Software Functions:
  • Anti-peeping code
  • Low battery warning
  • Privacy mode
  • User management
  • Real-time notifications
  • Anti-test locking
  • Anti-tamper alarm
  • Remote control
  • Video calling
  • Voice changer
  • Wandering detection

Supported Door Thickness

• 6068: 40-120 mm
• 5085: 40-100 mm

Working Environment

• Working Temperature: -10°C ~ 55°C
• Operating Humidity: 10% ~ 95%

In the Box

• Front Panel
• Rear Panel
• Hole Template
• Lock Body
• Standard Screw Bag
• Lock Body Screw Bag
• Battery
• Key Bag
• Square Rod
• Stickers
• Regulatory Information
• Quick Start Guide

Certifications

• CE (EMC / LVD / RED / RoHS)
• REACH SVHC
• WEEE
