Ricoh MP 2014AD A3 black and white multifunction printer, 20ppm, Print, Copy, Scan, Duplex, 600 x 600 dpi

Configuration

• Functions: Copy, Print, Scan
• Colour: No
• Memory (Standard): 256 MB
• Operation Panel: 4-line LCD

Physical Dimensions

• Mainframe Dimensions (WxDxH): 587 x 581 x 461 mm
• Weight: 29 kg or less

Media Handling

• Standard Input Capacity: 350 sheets
• Maximum Input Capacity: 1,350 sheets
• Standard Output Capacity: 250 sheets
• Maximum Output Capacity: 250 sheets

Paper Input Configuration (Standard)

• Trays: 250-sheet input tray, 100-sheet bypass tray, duplex unit

Paper Output Configuration (Standard)

• Tray: 250-sheet face-down output tray

Supported Media Types

• Standard Paper Input Tray: Thin paper, Plain paper, Recycled paper, Colour paper, Special paper, Middle thick paper, Pre-printed paper, Letterhead, Bond paper, Cardstock
• Bypass Tray: Additional support for Thick paper, Label paper, OHP transparencies, Envelopes

Maximum Paper Size: A3

• Media Weight: 52–216 g/m²

Connectivity

• Standard Interface: USB 2.0
• Optional Interface: Ethernet (10Base-T/100Base-Tx) with DDST unit Type M16

Copy Features

• Speed: 20 cpm (A4 LEF)
• First Copy Time: ≤10 seconds
• Resolution: 300 x 600 dpi (Standard), 600 x 600 dpi (Fine)
• Zoom Range: 50%–200%
• Duplex Copy: Supported
• ID Card Copy: Requires optional DDST unit Type M16

Print Features

• Print Speed (B/W): 20 ppm
• Resolution: 600 x 600 dpi
• Printer Drivers: DDST (GDI) (Requires optional DDST unit for network printing & scanning)
• Duplex Printing: Supported

Scan Features

• Scan Speed (A4, 200 dpi): 15 ipm (B/W), 6 ipm (Colour)
• Colour Scanning: Supported
• Resolution: Up to 600 x 600 dpi

Scan to Email

• Protocols: SMTP (TCP port 25)
• Authentication: SMTP authentication, POP3 before SMTP authentication
• File Types: JPEG, PDF (Colour/Greyscale), TIFF, PDF (B/W)

Scan to Folder

• Protocol: SMB 1.0
• File Types: JPEG, PDF (Colour/Greyscale), TIFF, PDF (B/W)

TWAIN Scanning

• Resolution: Up to 600 x 600 dpi
• Modes: Full Colour, Greyscale, Black & White

Supported Operating Systems

• Windows: Windows Server 2003/2003 R2/2008/2008 R2/2012/2012 R2, Windows Vista/7/8/8.1
