EZVIZ 2MP OUTDOOR PTZ 2MP Two-Way Talk 8 Mix Zoom Pic in pic, Dual lens

Model: CS-C8PF (1080P)

Camera

• Image Sensor: Dual-1/2.7" Progressive Scan CMOS
• Shutter Speed: Self-adaptive shutter
• Lens: 2.8 mm @ F1.6 + 12 mm @ F1.6
• PT Angle:
  • Pan: 340°
  • Tilt: 80°
• Minimum Illumination:
  • 0.05 Lux @ (F1.6 AGC ON)
  • 0 Lux with IR
• Lens Mount: M12
• Day & Night: IR-cut filter with auto switching
• DNR: 3D DNR
• WDR: Digital WDR
• BLC: Supports
• Black & White Night: 30 m / 98 ft

Video & Audio

• Max Resolution: 1920 × 1080
• Frame Rate: Max. 15fps (self-adaptive during network transmission)
• Video Compression: H.265 / H.264
  • H.265 Type: Main profile
• Video Bit Rate: Full HD; HD; Standard. Adaptive bit rate.
• Audio Bit Rate: Self-Adaptive
• Max. Bitrate: 2 Mbps

Network

• Wi-Fi Standard: IEEE802.11b, 802.11g, 802.11n
• Frequency Range: 2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth: Supports 20 MHz
• Security:
  • 64/128-bit WEP
  • WPA/WPA2, WPA-PSK/WPA2-PSK
• Transmission Rate:
  • 11b: 11Mbps
  • 11g: 54Mbps
  • 11n: 72Mbps
• Wi-Fi Pairing: AP pairing
• Protocol: EZVIZ Cloud Proprietary Protocol
• Interface Protocol: EZVIZ Cloud Proprietary Protocol
• Wired Network: RJ45 × 1 (10M/100M Adaptive Ethernet Port)

Function

• Smart Alarm: AI-powered Human Shape Detection
• Customized Alert Area: Supports
• Audio: Supports mic
• General Functions:
  • Anti-flicker
  • Dual-stream
  • Heartbeat
  • Password protection
  • Watermark

Storage

• Local Storage: MicroSD card slot (Max. 512GB)
• Cloud Storage: EZVIZ cloud storage

General

• Operating Conditions:
  • Temperature: -30ºC to 60ºC (14°F to 113°F)
  • Humidity: 95% or less (non-condensing)
• IP Grade: Weatherproof design
• Power Supply: DC 12V / 1A
• Power Consumption: Max. 12W
• Dimensions:
  • Camera: 154 × 116 × 164 mm (6.06 × 4.57 × 6.46 inch)
• Packaging Dimensions: 197 × 185 × 205 mm (7.76 × 7.28 × 8.07 inch)
• Weight:
  • Product: 578 g (20.39 oz)
  • With Package: 938 g (33.09 oz)

In the Box

• C8PF Camera
• 1.5-Meter Power Adapter
• Screw Kit
• Waterproof Kit
• Drill Template
• Regulatory Information
• Quick Start Guide

Certifications

• UL / FCC / CE / WEEE / REACH / ROHS
