EZVIZ 1080p 4MP Outdoor WiFi Security Camera, CS-H3C-R100-1K4WF, with IR Night Vision & AI Human Shape Detection for Home CCTV

EZVIZ CS-H3C-R100-1K4WF Security Camera - Specifications

Camera:

• Image Sensor: 1/2.7” Progressive Scan CMOS
• Minimum Illumination: 0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
• IR Night Vision Distance: Up to 98 ft / 30 m
• Shutter Speed: Self-adaptive shutter
• Lens: 4mm @ F2.0, view angle: 82° (Horizontal), 98° (Diagonal)
• Lens Mount: M12
• DNR: 3D DNR
• WDR: Digital WDR
• Day / Night Switch: IR-Cut filter with auto-switching

Video & Audio:

• Max. Resolution: 1080p (1920 × 1080)
• Frame Rate: Max 30fps; Self-Adaptive during network transmission
• Video Compression: H.265 / H.264
• Video Bit Rate: Full HD, HD, Standard. Adaptive bit rate.
• Audio Bit Rate: Self-Adaptive
• Max. Bitrate: 2 Mbps

Network:

• Wi-Fi Standard: IEEE 802.11b/g/n
• Frequency Range: 2.4 GHz ~ 2.4835 GHz
• Channel Bandwidth: Supports 20 MHz
• Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
• Transmission Rate: 11b: 11Mbps, 11g: 54Mbps, 11n: 144Mbps
• Wi-Fi Pairing: AP Pairing
• Protocol: EZVIZ Cloud Proprietary Protocol
• Interface Protocol: EZVIZ Cloud Proprietary Protocol
• Wired Network: RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

General:

• Dimensions: 72mm × 72mm × 157mm (2.83 × 2.83 × 5.98 inches)
• Package Dimensions: 227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inches)
• Weight: 250 g (8.82 oz) net, 447 g (15.77 oz) with package
• IP Grade: IP67
• Operating Conditions: -30°C to 50°C (-22°F to 122°F), humidity 95% or less (non-condensing)

Function:

• Detection: AI-Powered Human Shape Detection, Motion Detection
• Customized Alert Area: Supported
• Integration: Works with Alexa, Google Assistant, IFTTT
• General Functions: Anti-Flicker, Dual-Stream, Heartbeat, Mirror Image, Password Protection, Watermark

Storage:

• Local Storage: Supports microSD card (Up to 512 GB)
• Cloud Storage: Supports EZVIZ CloudPlay storage (Subscription required)

Power:

• Power Supply: DC 12V / 1A
• Power Consumption: Max. 6W

In the Box:

• H3c Camera
• Drill Template
• Screw Kit
• Waterproof Kit
• Power Adapter
• Regulatory Information
• Quick Start Guide

Certifications:

• CE, FCC, UKCA, UL, WEEE, RoHS, REACH
